Fine-Pixel Pitch LED Screen-Ultra Thin 1000 Series
Maxcolor 1000 series LED Screen is designed for indoor fixed installation application. It is made high precise die casting aluminum cabinet flatness and seamless installation. LED Displays can be mounted on the way directly without steel structure. All Data and power cables wiring from cabinets internal, easy connection, easy installation and easy maintenance.
- Light weight and slim cabinet
- Aluminum Cabinet Frame,1000x250mm LED cabinet design
- Full front maintenance, all the components could be serviced from front side
- Hot-connection Cabinet
- 3840 Hz Refresh Rate with 16-way PWM IC
DESCRIPTION
SPECIFICATION
Video
RELATED PRODUCTS
ULTRA SLIM & LIGHTWEIGHT DESIGN
Easy to operate,also saving installation cost and transportation cost
Cabinet Structure
- Aluminum material frame
- High precision, high strength
- Perfect heat dissipation.
- 33mm thickness
Front maintenance tool creative design
Maxcolor 1000*250mm double-side LED display with frontal service.The magnetic LED modules can be removed by tools in front side only 10 seconds.easy and convenient,save your cost and labor.
Module, receiving cards and power supplies can be maintained front, no maintenance channels needed.
ALUMINUM CABINET FRAME
The all-aluminum box design makes it have good heat dissipation performance.No need for additional fans for cooling.The appearance of the cabinet is more simple and more elegant.
Maxcolor 1000X250mm double side LED Screen
HOT SWAPPING WIRELESS CONNECTION
- Modules adopt HUB connection, safer signal transmission.
- The hot swapping technology is a key point that achieves thecontinuous operation and uninterrupted maintenance.
- Ultra-thin thickness, but roomy interior.
- Standardized design, extensive applications.
HIGH REFRESH IC
- PWM constant current outputAnti-interference
- Control the brightness precisely
VARIOUS INSTALLATION TYPE SUPPORT
Support hanging, stacking, wall mounted and ceiling mounted, solving the problem of maintaining space
LARGE VIEWING ANGLE
Full RGB color produce vivid pictures.160° super wide horizontal and vertical viewing allow for maximum audience engagement in short viewing distances.
SUPER EXCELLENT PERFORMANCE
High refresh rate ,High contrast ratio High grayscale ,supporting camera shooting and streaming live.
1000x250mm LED Screen Application
Fine-Pixel Pitch LED Screen-Ultra Thin 1000 Series
Ask for a quote
Specification
| Model Number | P1.95 | P2.5 | P2.976 | P3.91 |
| Pixel Pitch(MM) | 1.95 | 2.5 | 2.976 | 3.91 |
| LED Standard | SMD1515 | SMD1515 | SMD1515 | SMD2121 |
| Pixel Density(Dot/m²) | 262144Dot/m² | 160000Dot/m² | 112896Dot/m² | 65536Dot/m² |
| Module Size（MM） | 250X250 | 250X250 | 250X250 | 250X250 |
| Module Quantity(W×H） | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 | 4X1/3X1/2X1 |
| Cabinet Size（MM） | 1000X250X33/500X250X33 | 1000X250X33/500X250X33 | 1000X250X33/500X250X33 | 1000X250X33/500X250X33 |
| Cabinet Density(Dot/m²) | 512X128/266X128 | 400X100/200X100 | 336X84/168X84 | 256X64/128X64 |
| Cabinet Material | Aluminum | Aluminum | Aluminum | Aluminum |
| Cabinet Weight | 5.8kg/2.9kg | 5.8kg/2.9kg | 5.8kg/2.9kg | 5.8kg/2.9kg |
| Maintenance Mode | Front | Front | Front | Front |
| Brightness | 700nits | 800nits | 800-1000nits | 1000-1200nits |
| Refresh Rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Power Consumption(Ave) | 100-200W/m² | 100-200W/m² | 100-200W/m² | 100-200W/m² |
| Power Consumption (Max) | 800W/m² | 800W/m² | 800W/m² | 800W/m² |
| Viewing Angle | 160/160(H/V) | 160/160(H/V) | 160/160(H/V) | 160/160(H/V) |
| Scan | 1/32 | 1/25 | 1/28 | 1/16 |
| Operation Power | AC90-264V 47-63HZ | AC90-264V 47-63HZ | AC90-264V 47-63HZ | AC90-264V 47-63HZ |
| Working Humidity | 10~90% RH | 10~90% RH | 10~90% RH | 10~90% RH |
| Working Temperature (℃) | -20℃~+40℃ | -20℃~+40℃ | -20℃~+40℃ | -20℃~+40℃ |
| Life Span | ≥100000Hours | ≥100000Hours | ≥100000Hours | ≥100000Hours |
