The best choose for supermarket retail shelves-Shelf Edge LED Display
DESCRIPTION
SPECIFICATION
Video
RELATED PRODUCTS
Shelf led display screen uesd on supermarker shelves or retail shelves.Shelf led display screen can show picture,music,video and pirce that you want shows.Compared to traditional advertising,Shelf led display screen can display product information more vividly and leave a deep impression on customers.Shelf led display screen can save labor cost and time,help you save more money to buy other useful products.Shelf led display screen liberates paper and trees and makes nature more environmentally friendly.
Maxcolor LED Shelf Edge Led Displays
Various sizes are available
Suitable for all kinds of standard shelves, andcan be assembled according to shelf lengthflexibly.
MaxcolorLED shelf LED display
The buckle design to prevent cable from loosening,ensuring the stablity of the display.
shelf LED display detail
Easy Control
4G,WiFi,USB,Lan control way,easy to change thecontent
MaxcolorLED shelf LED display control type
Shelf Edge Led Display application
The best choose for supermarket retail shelves-Shelf Edge LED Display
Ask for a quote
Specification
| Display Side(W*H) | 300x60mm | 600x60mm | 900x60mm | 900x240mm | 1200x60mm |
| Model Number | P1.2 | P1.2 | P1.2 | P1.2 | P1.2 |
| Pixel Pitch(MM) | 1.2mm | 1.2mm | 1.2mm | 1.2mm | 1.2mm |
| LED Spec | GOB | GOB | GOB | GOB | GOB |
| Pixel Density | 694444.4444Dot/m² | 694444.4444Dot/m² | 694444.4444Dot/m² | 694444.4444Dot/m² | 694444.4444Dot/m² |
| Module Resolution(dots) | 125×50 | 125×50 | 125×50 | 250×100 | 125×50 |
| Module Size(mm) | 150×60 | 150×60 | 150×60 | 300×120 | 150×60 |
| Module Thickness(MM) | 10MM | 10MM | 10MM | 10MM | 10MM |
| Cabinet Type | Profile box | Profile box | Profile box | Profile box | Profile box |
| Cabinet Material | Aluminium profile steel plate | ||||
| Cabinet Size(MM) | 303×63 | 603×63 | 903×63 | 903×243 | 1203×63 |
| Cabinet Thickness(MM) | 22 | 22 | 22 | 22 | 22 |
| Cabinet Weight | 0.35kg | 0.35kg | 0.35kg | 0.35kg | 0.35kg |
| Reference Average Power(W) | 13.7 | 27.3 | 41 | 164.1 | 54.7 |
| Brightness | ≥800nit | ≥800nit | ≥800nit | ≥800nit | ≥800nit |
| Refresh Rate | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| Row Driven IC | 7258 | 7258 | 7258 | 7258 | 7258 |
| Viewing Angle | ≥140° | ≥140° | ≥140° | ≥140° | ≥140° |
| Driving Method | 1/32 | 1/32 | 1/32 | 1/32 | 1/32 |
| Storage Temperature | -30℃ – 80℃ | -30℃ – 80℃ | -30℃ – 80℃ | -30℃ – 80℃ | -30℃ – 80℃ |
| Working Humidity | 10%-80%RH (No condensation) | ||||
| Operating Temperature | Indoor Type:-10 ℃— 40 ℃;Indoor Type:-20 ℃— 50 ℃ | ||||
| Working Voltage | DC5V±10% | DC5V±10% | DC5V±10% | DC5V±10% | DC5V±10% |
| Life Span | ≥100000Hours | ≥100000Hours | ≥100000Hours | ≥100000Hours | ≥100000Hours |
