Outdoor Fixed Installation waterproof Led Screen-W Series
Best choose of Highway advertising outdoor led billboard.
- 500*1000mm LED Display Cabinet
- High precision die-casting magnesium Cabinet
- Fixed Installation or Perimeter Sports
- High brightness levels
- 3 Year Warranty
DESCRIPTION
SPECIFICATION
Video
RELATED PRODUCTS
DESCRIPTION
SPECIFICATION
Video
RELATED PRODUCTS
Have rear serving led panel for options
Have 500x1000mm and 1000×500 LED cabinets for options
500X1000mm LED Panel
Ultrathin，Only 70MM Thickness
Ultralight
＜11kg/m² weight
Super waterproof
IP65 rear and front modular led screen
Ant-dust, anti-humidity and anti-corrosion LED panel is all weather application
SEAMLESS SPLICING
Seamless Splicing For A Better Display Effect
Project Case
In our effort to provide the best solution for each individual customer and project, we know how
important it is to consider all of the variables, including exposure and weather.
Outdoor Fixed Installation waterproof Led Screen-W Series
Ask for a quote
Specification
| Model Number | P3.91 | P4.81 | P5.2 | P6.25 | P10.4 |
| Pixel Pitch(MM) | 3.91 | 4.81 | 5.2 | 6.25 | 10.4 |
| LED Standard | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD3535 |
| Density | 65536dot/㎡ | 43264dot/㎡ | 36864dot/㎡ | 25600dot/㎡ | 9216dot/㎡ |
| Pixel Composition | RGB | RGB | RGB | RGB | RGB |
| Color Temperature | 5500-9300K | 5500-9300K | 5500-9300K | 5500-9300K | 5500-9300K |
| Power Consumption | 230w/m²~800W/m² | 230w/m²~800W/m² | 230w/m²~800W/m² | 230w/m²~800W/m² | 230w/m²~800W/m² |
| Cabinet Size（MM） | 1000X500MM/1000X1000MM | 1000X500MM/1000X1000MM | 1000X500MM/1000X1000MM | 1000X500MM/1000X1000MM | 1000X500MM/1000X1000MM |
| Cabinet Weight | 22kg/m² | 22kg/m² | 22kg/m² | 22kg/m² | 22kg/m² |
| Brightness | 4000cd/m² | 4000cd/m² | 5000cd/m² | 5000cd/m² | 5000cd/m² |
| Refresh Rate | 1920HZ-3840HZ | 1920HZ-3840HZ | 1920HZ-3840HZ | 1920HZ-3840HZ | 1920HZ-3840HZ |
| Viewing Angle | 140°/140°（H/V） | 140°/140°（H/V） | 140°/140°（H/V） | 140°/140°（H/V） | 140°/140°（H/V） |
| Driving Method | 1/16 | 1/13 | 1/8 | 1/5 | 1/2 |
| Gray scale | 65536 | 65536 | 65536 | 65536 | 65536 |
| IP Rating | IP68 | IP68 | IP68 | IP68 | IP68 |
| Working Temperature | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ |
| Continuous working time | ＞72hours | ＞72hours | ＞72hours | ＞72hours | ＞72hours |
| Life Span | 100000Hours | 100000Hours | 100000Hours | 100000Hours | 100000Hours |
